JP-SC092 30Hz (B/W Sensor), 25Hz (HDR Sensor) MJPG / YUY2 Video Output

JP-SC092 Dual-Lens 2MP Glass-Lens USB Wide Dynamic Range Camera Module

Product Overview

The JP-SC092 Dual-Lens 2MP Glass-Lens USB Wide Dynamic Range Camera Module is a compact dual-sensor imaging solution featuring 1/2.7" industrial-grade CMOS sensors for both monochrome and HDR channels, each delivering 1920 × 1080 resolution. Engineered with precision glass optical lenses and infrared fill-light technology, this module captures both near-infrared and visible light simultaneously — enabling effective liveness detection by leveraging the principle that screens cannot reproduce IR images, while paper-based spoofing attempts are identified through texture and color analysis. This dual-channel approach effectively prevents photo, video, and other spoofing attacks with greater accuracy and faster processing than single-lens alternatives. With 85dB HDR dynamic range, 0.01lux minimum illumination, and M12 lens mount supporting various focal lengths, the JP-SC092 is the ideal choice for facial recognition terminals, access control systems, and biometric authentication applications.

Key Advantages

• Effective Spoofing Prevention: Infrared + visible light dual-camera architecture ensures screen-based attacks cannot reproduce IR images, while paper-based spoofing is identified through IR texture and color analysis — delivering significantly higher liveness detection accuracy than single-lens solutions.

• Industrial-Grade 1/2.7" CMOS Sensors: Features PS5268 and OV2735 CMOS sensors with 3.0μm × 3.0μm pixel size for both B/W and HDR channels — delivering consistent, reliable imaging across diverse operating environments.

• 85dB Wide Dynamic Range: HDR sensor provides 85dB dynamic range for clear imaging in high-contrast scenes — from bright backlight to dim interiors.

• High SNR for Clean Images: B/W sensor achieves ≥36dB SNR while HDR sensor delivers ≥41dB SNR — ensuring low-noise images even in challenging lighting conditions.

• Precision Glass-Lens Optics: Engineered with high-quality glass lenses offering superior light transmission, thermal stability, and scratch resistance — delivering consistent image quality across extreme temperatures from -10°C to 65°C where plastic lenses would degrade.

• UVC Compliance: Standard USB interface with 480Mb/s transfer rate — plug-and-play connectivity with Windows, Linux, Mac, and Android, no driver development required.

• Compact, Thermally Efficient Enclosure: Measuring just 80mm × 16mm × 17.8mm with ±0.3mm tolerance, the module fits easily into space-constrained access control terminals and embedded authentication devices.

Why Choose This Module?

• Industry-Leading Liveness Detection: The JP-SC092's dual-sensor architecture provides a fundamental security advantage over single-lens modules. Screens cannot reproduce IR images, effectively blocking all screen-based spoofing attempts. Paper-based attacks are defeated through advanced texture and color analysis of IR images. This multi-layered approach delivers unmatched protection against presentation attacks — essential for high-security applications requiring real-person verification.

• Glass-Lens Clarity for Consistent Performance: Plastic lenses degrade over time, scratch easily, and lose focus with temperature changes. Glass lenses maintain optical clarity through years of field deployment, resist scratches, and hold focus across the full -10°C to 65°C operating range. The JP-SC092 is built for applications where cameras are touched, cleaned, or exposed to dust and debris — delivering long-term image quality that plastic-lens modules cannot match.

• Compact Design Without Compromise: At just 80mm × 16mm × 17.8mm, the JP-SC092 delivers full dual-sensor functionality in a remarkably compact form factor — fitting easily into space-constrained access control terminals, facial recognition kiosks, and embedded authentication devices.

• Industrial-Grade Reliability: Built with 1/2.7" industrial-grade CMOS sensors and engineered for -10°C to 65°C operation, the JP-SC092 maintains consistent performance in demanding environments — from outdoor entry points to factory floor installations.

• Faster Processing, Higher Accuracy: The dual-sensor architecture enables simultaneous near-infrared and visible-light capture, allowing faster processing and more accurate liveness detection than sequential single-sensor approaches. Users experience quicker recognition without compromising security.

JP-SC092 30Hz (B/W Sensor), 25Hz (HDR Sensor) MJPG / YUY2 Video Output Images
